2006 Ford Excursion
2006 Ford Excursion
Key and Remote Programming Information
Click to Expand
Add Duplicate Key (Requires two working keys):
1. Insert an existing key into the ignition cylinder.
2. Turn the ignition cylinder to ON (RUN) and back to OFF.
3. Remove the existing key and, within five seconds, insert a second key and turn it to ON (RUN) then back OFF.
4. Insert the new key before ten seconds have elapsed and turn it to ON (RUN). Leave it on for one second and turn back to OFF
5. The security light will light up for three seconds to indicate that the new key has been successfully.
programmed.
Step by Step Programming Instructions:
On-board programming is not available for this model.
Key Blank:
597602 / H72-PT
Transponder/Clone Info:
Clone tool with H72-GTK, FD21UTK24, H72-N-PHT, 692574 or TPX5-FO-15D.P
Replacement key blank by Brand:
Ilco – H72-PT | Strattec – 597602 | Jet – H72-PHT | Bianchi – BH72-PT | Hata – HAT-H72-HPT | JMA – TP02-FO-15D.P | Substitute – 598333
Key Codes:
0001X–1706X
Code Location:
No codes on vehicle
Tumbler Locations
| Spaces | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
|---|---|---|---|---|---|---|---|---|
| IGNITION | X | X | X | X | X | X | X | |
| DOOR | X | X | X | X | X | X | ||
| TRUNK | X | X | X | X | X | X | ||
| GLOVE* | X | X | X | |||||
| STOWAGE | X | X | X | X |
